| Board accommodated length |
127.6 millimeters nominal single board |
| Board accommodated width |
1.5 millimeters minimum and 1.8 millimeters maximum |
| Body style |
Straight edge type w/mounting flange |
| Connector locking method |
Friction |
| Contact maximum ac voltage rating in volts |
230.0 single mating end single contact grouping |
| Contact maximum current rating in amps |
3.0 single mating end single contact grouping |
| Contact maximum dc voltage rating in volts |
330.0 single mating end single contact grouping |
| Contact material |
Copper alloy single mating end single contact grouping |
| Contact position arrangement style |
2 rows of independent contacts inserted board single mating end |
| Contact removability |
Nonremovable single mating end single contact grouping |
| Contact surface treatment document and classification |
Mil-g-45204 mil spec 1st treatment response single mating end single contact grouping |
| Contact surface treatment |
Gold single mating end single contact grouping and nickel single mating end single contact grouping |
| Distance between mounting facility centers |
145.8 millimeters nominal |
| Environmental protection |
Corrosion resistant |
| Included contact quantity |
100 single mating end single contact grouping |
| Included contact type |
Leaf spring single mating end single contact grouping |
| Insert material |
Plastic polysulfone single mating end |
| Overall length |
152.8 millimeters nominal |
| Overall width |
6.0 millimeters nominal |
| Mating end quantity |
1 |
| Precious material and location |
Contact surfaces gold |
| Precious material and weight |
0.100 gold grains, troy |
| Precious material |
Gold |
| Terminal location |
Back single mating end single contact grouping |
| Terminal type |
Tab, solder lug single mating end single contact grouping |
